Sealey Yankee Telescopic Vertical Transmission Jack

The Sealey Yankee 800kg Telescopic Vertical Transmission Jack is the heavy-duty solution for workshops working with larger vehicles and heavier gearbox assemblies. With an 800kg capacity, this robust model is specifically designed for commercial vehicles, 4x4s, and heavier transmissions where additional lifting capability is essential.

Built to handle demanding applications, this jack features twin axis saddle adjustors that allow the gearbox support to be angled in any direction, ensuring perfect alignment even with bulky transmission units. The 2-stage telescopic piston design provides the reduced clearance access needed when working beneath larger vehicles, whilst the hardened chrome plated piston rod delivers reliable, smooth operation.

Foot pedal operation keeps your hands free for controlling heavy transmissions, and the spring loaded dead man's safety release control minimises the risk of inadvertent lowering during critical operations. Four heavy duty castors with non-marking nylon wheels on a sturdy base provide the stability and manoeuvrability required when handling heavier loads.

Features and Benefits:
• 800kg capacity for heavy-duty transmissions and commercial vehicles
• Twin axis saddle adjustors for versatile positioning
• 2-stage telescopic piston for confined space access
• Hands-free foot pedal operation
• Spring loaded safety release control
• Heavy duty castors with non-marking wheels for easy movement

Specifications:
Base Size: 600 x 600mm
Brand: Viking
Capacity: 1000kg
Fixed/Adjustable Saddle: Adjustable
Maximum Saddle Height: 1930mm
Minimum Saddle Height: 910mm
Nett Weight: 58kg
Pump Strokes to Maximum Height: n/a
Ram Extensions: 2
Saddle Adjustment - Left-to-Right: n/a
Saddle Tilt - Backward: 10°
Saddle Tilt - Forward: 10°
